Specifications
Prod Model: |
TOR 250 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Transmission Type: |
Manual |
Engine Type: |
4 Stroke |
Structure: |
Without Door |
Displacement: |
250CC |
Transmission System: |
Chain Drive |
Fuel: |
Gas / Diesel |
Brake Type: |
Disc Brake |
Maximum Speed: |
50-75 km/h |
Power: |
>1000W |
Certification: |
ISO9001 |
Brand: |
Kayo |
Product Description
Engine:250 | Frame:Designed and made by Kayo |
Bore*Stroke:70mm*65mm | Handle Bar:Alloy |
Compression Ratio:9.0:1 | Gears:Manual clutch, 5 gears(4 front, 1 reverse) |
Max. Power(kw/rpm):14.0/8000 | Rim:Steel |
Max Torque(N.m/r/min):18.5/6500 | Tyres:Front 10" Rear9" |
Ignition:CDI | Front Shock:345mm Non-adjustable |
Start:Electric | Rear Shock:390mm Adjustable |
Transmission:13T-41T KMC520H | Carburetor:Mikuni |
Seat Height:800mm | Swing Arm:Steel |
Wheel Base:1090mm | Brake:Disc |
Length:1620mm | Fuel Capacity:6L |
Dry Weight:165kg | Max Speed:70KM/H |
|
Packing Dimensions:1680*1140*810mm |
20'GP:12PCS |
40'HQ:42PCS |
KAYO ATV Strong Points:
1, Strong structure: We designed and made the frame and linkage all by ourselves in own special workshop, to ensure the real high quality and best performance;
2, Riding comfort: We designed the seat by ourselves and choose the car supplier to make, we choosed the Honda shock supplier for our ATV models except Space1 KD70;
3, Steering performance: agility and easy to operate
4, Small shaking: We tested our bike with long period and with our accurate design, to let the engine match our frame very well.
5, Warranty: We give 1 year warranty for our ATV models main parts (engine, braking systems, linkages ,frame and suspension)
