Specifications
Prod Model: |
STROM 150 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Engine: |
150 |
Max. Power(Kw/Rpm): |
7.3/8500 |
Max Torque(N.M/R/Min): |
9.2/6500 |
Start: |
Electric |
Tyres: |
Front 10" Rear9" |
Front Shock: |
270mm Non-Adjustable |
Rear Shock: |
305mm Non-Adjustable |
Fuel Capacity: |
7L |
Transmission Type: |
Semi-Automatic |
Engine Type: |
4 Stroke |
Structure: |
Without Door |
Displacement: |
150CC |
Transmission System: |
Chain Drive |
Fuel: |
Gas / Diesel |
Brake Type: |
Disc Brake |
Maximum Speed: |
50-75 km/h |
Power: |
>1000W |
Certification: |
ISO9001 |
Brand: |
Kayo |
Product Description
Engine:150 | Frame:Designed and made by Kayo |
Bore*Stroke:56mm*57mm | Handle Bar:Steel |
Compression Ratio:8.8:1 | Gears:Semi-Auto, 4 gears(3 front, 1 reverse) |
Max. Power(kw/rpm):7.3/8500 | Rim:Steel |
Max Torque(N.m/r/min):9.2/6500 | Tyres:Front 10" Rear9" |
Ignition:CDI | Front Shock:270mm Non-adjustable |
Start:Electric | Rear Shock:305mm Non-adjustable |
Transmission:14T-45T KMC428 | Carburetor:Standard |
Seat Height:745mm | Swing Arm:Steel |
Wheel Base:1000mm | Brake:Disc |
Length:1540mm | Fuel Capacity:7L |
Dry Weight:121kg | Max Speed:58KM/H |
|
Packing Dimensions:1460*860*720mm |
20'GP:30PCS |
40'HQ:63PCS |
KAYO ATV Strong Points:
1, Strong structure: We designed and made the frame and linkage all by ourselves in own special workshop, to ensure the real high quality and best performance;
2, Riding comfort: We designed the seat by ourselves and choose the car supplier to make, we choosed the Honda shock supplier for our ATV models except Space1 KD70;
3, Steering performance: agility and easy to operate
4, Small shaking: We tested our bike with long period and with our accurate design, to let the engine match our frame very well.
5, Warranty: We give 1 year warranty for our ATV models main parts (engine, braking systems, linkages ,frame and suspension)
