LPG Scooter (FQ125-3)

Specifications

Prod Model:	FQ125-3

Product Description

Dimensions and weight
Overall length 1960mm
Overall width 680mm
Overall height 1150mm
Wheelbase 1350mm
Minimum over ground space 140mm
Net weight 110kg
Engine
Type mono cylinder, 4 strokes, reinforced wind cooling
Cylinder number 1
Concentration ration 10.5: 1
Cylinder diameter and stroke 52.4*57.8mm
Cylinder working capacity 124.6ml
Clutch dry, automatic centrifugal
Speed change mode stepless speed change
Deceleration ratio 8.6
Ignition mode CDI
Minimum stable rotation speed 1900r/min
Nominated power rate and corresponding rotation speed 5.4/7000(kw/r/min)
Maximum torque and corresponding rotation speed 7.8/6000(N. M/r/min)
Startup mode Electric/ foot
Performance
Brake distance ≤6m(vehicle speed 30km/h)
Maximum load 150kg
Maximum speed ≤65km

Creeping capability ≤5°
Economical gas consumption ≤4L/100km
Minimum turning radius 48°
Turing angle(left, right) 3m
Electrical system
Battery 7AH/12V
Headlight 35W/35W/12V
Turning indicator 10W/12V
Taillight 5W/15W/12V
Instrument light 3W/12V
Horn 12V/1.5A
Fuse 6A/50A

Gas and machine oil
Gas Vehicle use LPG
Gas tank capacity 5L
