Specifications
Prod Model: |
J1 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Starting System: |
Electric Start |
Certification: |
CE |
Engine: |
4 Stroke |
Displacement: |
126-250CC |
Condition: |
New |
Fuel: |
Gas / Diesel |
Cylinder Quantity: |
1 |
Product Description
ENGINE
Engine type: 250CC, 2-valves, single cyclinder, 4-stroke, air cooled, electric
Bore X Stroke: 65.5x68.2mm
Compression Ratio: 10.7: 1
Max power: 23HP/ 11000rpm
Min Fuel Consumption: < =354G/KW. H
Max torquer: 20.3N. M/9700rpm
Taansmission system: 5 speed, international gear
Lgnition mode: CDI
Clutch: Manual, wet mutiple plate
CHASSIS
Frame: Heavy duty strengthened chromolly, equiped with linkage
Swing arm: Heavy duty alloy swing arm, with linkage connector
Suspension system: Front fork: Size: 54/60-940mm, up-side-down type, 1-adjustment, 300mm stroke
Rear shock: Size: 490mm, compression and rebound adjustment, 190mm stroke, wheel traval: 300mm
Brake system: Hydraulic disc brake, special designed disc for sufficient brake, disc size:
Front: 240mm, rear: 240mm
Maximum load: 386lb/(175kgs)
Tank Capacity: 2.6gal/(10L)
G. W/N. W: 255lb/238lb(116kg/108kg)
Carburetor: MOJO
Dimensions(L*W*H): 2060X800X1240mm
Carton size: 1820X460X830mm
Container: 40units 20"FCL 80units 40" FCL 120units 40HQ FCL
Seat Height: 38in/960mm
Wheel base: 56in/1410mm
Ground Clearance: 13in/320mm
Engine and Rear sprocket: 15/51T, 428# Chains.
Rim Size: Front 21/ Rear 18
Tire size Front/Rear: 80/100-21 100/90-18
