Electric Mini Scooter 250W, 24V
| Price: | US $ 180-200/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 192/Piece |
| Pay Type: | L/C,T/T,D/P |
Specifications
| Prod Model: | SQ250DH-2 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Over Dimension(L*W*H): | 950mm*285mm*520mm |
| Motor Type: | Brushed DC,250W/24V |
| Motor Max Loaded AMPS: | 17.8A |
| Torque: | 1.21(N.M) |
| Max Rpm: | 2700±7.5%(Rpm) |
| Controller Type: | Air Cooled,Non Water-Proof; Brake Shutoff,Charger |
| Battery: | Lea-Acid Battery,12V/7ah*2PCS |
| Turning Angle: | 32 |
| Seat Height: | 340mm |
| Wheel Base Distance: | 635mm |
| Running Distance: | <45KM |
| Motor: | Brush |
| Max Speed: | <20km/h |
| Battery Type: | Lead-acid Battery |
| Frame Material: | Steel |
| Voltage Of Battery: | 24V |
| Power: | 200-250W |
| Certification: | CE |
| Wheel Hub: | Alloy Hubs |
| Folded: | Folded |
| Charging Time: | 6-8h |
| Brake: | Mechanical Disc,Left Handle Control |
| Maximum Loading Capacity: | <45kgs |
| Wheel Size: | 110/50-6.5 |
Product Description
This is our factory
Specification
| Model | 250DH-2 | |
| Products Size(L*W*Hmm) | 920×400×720 | |
| Motor Type | brushed DC , 250W/24V | |
| Motor Max Loaded Amps | 17.8A | |
| Torque | 1.21(N.m) | |
| Max RPM | 2700±7.5%(rpm) | |
| Controller Type | Air cooled, non water -proof; brake shutoff, charger port | |
| Battery | Lead-Acid Battery,12V /7AH*2pcs | |
| Charging Time | 6-8 hours | |
| Battery Charger | Input-100-240VAC,50/60HZ,1.8A Max; Output-DC 24V,1.5A | |
| Special Features | Dismountable Handle bar | |
| Turning Angle | 32º | |
| Transmission Ratio | 92/11 | |
| Seat Height | 340 mm | |
| Wheel base Distance | 635 mm | |
| Front & Rear Tire and Rim | 110/50-6.5 | |
| Maximum Carrying Capacity | 45kgs | |
| 90 mm | |
| Maximum Speed | Low speed :11km/h ; high speed:21 km/h | |
| Maximum Distance Range | 13 km | |
| Control System | handle bar control | |
| Throttle Type | tum control | |
| Front & Rear Braking System | Mechanical disc, left handle control | |
| Drive System | Chian drive | |
| Brake Distance | ≤2m (11km/ h); ≤4m (21km/ h) | |
| Packing Size(L*W*Hmm) | 950×285×520 | |
| N.W/G.W | 23kgs/26kgs | |
| Container loading(20FT/40FT/40HQ): | 192/392/490 |
Loading capacity:
192pcs/20FT; 392pcs/40FT; 490pcs/40HQ
