Specifications
Prod Model: |
JUNMA UTV150 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Optional Specification: |
Windshield and Horn |
Color: |
Red,Blue,Yellow,Green,etc. and Veins |
Type: |
Short Type and Longer Type |
Transmission System: |
Chain Drive |
Transmission Type: |
Automatic |
Certification: |
ISO9001 |
Engine Type: |
4 Stroke |
Fuel: |
Gas / Diesel |
Displacement: |
150CC |
Structure: |
Two Side Doors |
Maximum Speed: |
50-75 km/h |
Brake Type: |
Disc Brake |
Product Description
Company Introduction
Jinan Shanglong International Trade Co., Ltd. Is located in Jinan city, P. R. China. Our company is a professional factory which manufactures and exports ATV(all-terrain vehicle) and UTV(utility vehicle).
Since the establishment of our company in 2003, we have devoted a significant amount of time and energy to research and develop products. We have got the certification of ISO9001 and we strictly stick to 5S manufacturing management (sort, organize, shine, standardise, sustain) to make sure that no unqualified products flow into the public market, and we always pursue consumerism as our basic rule of servicing customers. The displacement of our vehicles range from 50CC to 400CC. The 400CC ATV have attained certification of EEC, and 150CC ATV&UTV have attained certification of EPA. Our products attract international customers by new style and high quality. Our main market is North American, Western Europe, Australia, South America, Middle East and Asia.
Our company insists on the theory: "To persist in quality, To develop with sincerity". We are constantly looking for opportunities to build new business relationships with companies from all over the world. If you are interested in any of our products, please do not hesitate to contact us. Our qualified staff will do their utmost to supply you with first-class products and service.
Item |
Specification |
Engine type |
Single cylinder, 4-stroke, CVT |
Displacement |
149.6CC |
Bore x stroke |
57.4X57.8 |
Compression ratio |
9.5:1 |
Ignition |
CDI |
Cooling system |
Air cooling |
Starting system |
Electric |
Vehicle dimension |
2285mm, 2435mm x 1290mm x 1397mm |
Cargo bed |
410mm x 852mm x 220mm |
Wheelbase |
1650mm, 1800mm |
Front tread |
1020mm |
Rear tread |
965mm |
Ground clearance |
152mm |
Seat height |
500mm |
Dry weight |
245kg |
Fuel capacity |
9.5L |
Cargo bed load capability |
150kg |
Towing capability |
2000lb |
Final Drive |
Chain |
Brake system front/rear |
Foot Activated,4 wheel hydraulicdisc |
Suspension |
F:Single A-arm R:Swing arm |
Steering |
Gear box |
Front tyre size |
19x7-8 |
Front wheel size |
8x5.5 |
Rear tyre size |
20x10-9 |
Rear wheel size |
9x8 |
Top speed |
60km/h |
Packing Size |
2290mmx1300mmx855mm |
Waterproof |
0.2m |
Max climbing gradient |
15 ° |
Min opernation temperature |
-20 ° C |
Max opernation temperature |
40 ° C |
Max torque and rotate speed |
9.8N.m(4000r/min) |
Rated power and rotate speed |
6.8kw(5500r/min) |
Gas consumption/100km |
4.5L |
