Specifications
Prod Model: |
JUNMA UTV150 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Color: |
Optional |
Transmission System: |
Chain Drive |
Transmission Type: |
Automatic |
Certification: |
ISO9001 |
Engine Type: |
4 Stroke |
Fuel: |
Gas / Diesel |
Displacement: |
150CC |
Structure: |
Two Side Doors |
Maximum Speed: |
50-75 km/h |
Brake Type: |
Disc Brake |
Condition: |
New |
Power: |
>1000W |
Brand: |
Junma |
Product Description
We are a company which specializes in manufacturing and exporting UTV.
Our 150cc UTV has gained the certification of EEC and EPA. We export thousands of UTV to America, Russia, Brazil, Mexico, Thailand, Philippines, Portugal, Czech, etc.
Our 150cc UTV is longer than other suppliers' same-displacement UTV, which is more suitable for adults. The cab is long enough.
Our UTV is equipped with dashboard, windshield, rear view mirror, head lights, turn lights, tail lights, horn, sun roof, winch, side iron doors, etc.
We provide 24 kinds of colors and patterns for your option. According to your preference, we can make UTV more pretty and practical.
Our UTV has a high reputation because of the good quality and competitive price. We are now looking for partners who would like to cooperate with us from all over the world. We always our customers sincerely.
For mutual benefit, please do not hesitate to join us!
Item | Specification |
Engine type | Single cylinder, 4-stroke, CVT |
Displacement | 149.6CC |
Bore x stroke | 57.4mmX57.8mm |
Compression ratio | 9.5:1 |
Ignition | CDI |
Cooling system | oil cooled |
Starting system | Electric |
Vehicle dimension | 2435mm x 1290mm x 1397mm |
Cargo bed | 410mm x 852mm x 220mm |
Wheelbase | 1800mm |
Front tread | 1020mm |
Rear tread | 965mm |
Ground clearance | 152mm |
Seat height | 500mm |
Dry weight | 245kg |
Maximum rider weight | 68kg(each rider) |
Fuel capacity | 9.5L |
Cargo bed load capability | 150kg |
Towing capability | 2000lb |
Final Drive | Chain |
Shift type | F/N/R |
Brake system front/rear | Foot Activated,4-wheel hydraulic disc |
Suspension | F:Single A-arm; R: dual shock swing arm |
Steering | Gear box |
Front tyre size | 19x7-8 |
Front wheel size | 8x5.5 |
Rear tyre size | 20x10-9 |
Rear wheel size | 9x8 |
Tire pressure | F: 97kPa; R: 145kPa |
Top speed | 60km/h |
Packing Size | 2290mmx1300mmx855mm |
Waterproof | 0.2m |
Max climbing gradient | 15 ° |
Min opernation temperature | -20 ° C |
Max opernation temperature | 40 ° C |
Max torque and rotate speed | 9.8N.m(4000r/min) |
Rated power and rotate speed | 6.8kw(5500r/min) |
Gas consumption/100km | 4.5L |
Standard specification | windshield, sunroof, dashboard, turn lights, horn, rearview mirror |
Optional specification | Iron doors +$120 |
winch +$30 |
