Product Description
Measurement and WeightL 2650mm
W 1100mm
H 1110mm
Wheel base 1290mm
Dry mass 238kg
Ground clearance 155mm
Engine
Engine style Single cylinder, 4stroke, water-cooled
Engine type QJ169MMM-2
Bore * stoke 69mm * 66. 8mm
Compression ratio 9: 1
Max power 12. 5kw/5000r/min
Ignition CDI
Starting mode Electric starter
Clutch Dry, centrifugal
Transmission
Driving system Chain drive
Front tire 21X7-10 tubeless
Rear tire 22X11-10 tubeless
Electrical
Battery 12V
Chassis
Front brake Hand operation, double disc
Rear brake Hand operation, single disc
Max speed >=90km/h
Economic fuel consumption 2. 8L/100km
Max load 300kg
Capacity
Fuel tank(including res) 9. 3L
China Qianjiang Group is the largest motorcycle producing and selling company in China, with annual output of more than 1, 000, 000 units. It occupies an area of 670, 000m² and has over 11, 000 staff members. Our company produces the motorcycles ranged from 50cc to 250cc, and we also manufacture the products concerned with the motorcycle, such as the mini motorcycle, ATV, gas-scooter, generator, high pressure water cleaner, garden tools, power pump, vacuum pump. Among these products, 20% products are exported to Europe, America, Middle East, Northeast Asia and Africa more than 68 countries. Our products are well received by our clients.
