Specifications
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
|---|---|
| Certification: | EPA |
| Transmission System: | Chain Drive |
| Engine Type: | 4 Stroke |
| Structure: | Two Side Doors |
| Transmission Type: | Automatic |
| Displacement: | 200CC |
Product Description
Features:1) Engine: 200CC, Water-cooled, single cylinder, 4-stroke
2) Max. Load: 150kg
3) Max. Speed: 65km/h
4) Transmission: Chain
5) Clutch mode: Manual clutch, 5 speed with reverse
6) Bore x stroke: 63.5 x 62.2mm
7) Max. Power: 12kW/8, 000r/min
8) Max. Torque: 15N. M/6, 000r/min
9) Compression ratio: 10.15: 1
10) Min. Turning radius: 3, 000mm
11) Min. Fuel consumption: 354g/kWh
12) Min. Ground clearance: 190mm
13) Start system: Electric start
14) Brake: (F/R) drum / hydraulic disc brake
15) Front and rear suspension, with double "A" swing arm
16) Shift speed type: Five speed, with inner reverse gear
17) Front tire: 19 x 7-8
18) Rear tire: 18 x 9.5-8
19) Wheel base: 1, 100mm
20) Ignition type: CDI
21) Fuel tank capacity: 9.0L
22) Battery: 12V x 9Ah
23) Available colors: Black, red, yellow, blue, green
24) Dimensions: 1, 670 x 895 x 1060mm
Outer packing:
7 layers carton and steel frame
N. W.: 138kg /G. W.: 170kg
Carton size: 1, 560 x 920 x 750mm
Conveyance:
Qty/20' FCL: 28PCS Qty/40' HQ: 63PCS
