Specifications
Prod Model: |
FPA700E-A |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Brake Type: |
Disc Brake |
Maximum Speed: |
>75 km/h |
Fuel: |
Gas / Diesel |
Certification: |
EEC |
Transmission System: |
Shaft Drive |
Engine Type: |
4 Stroke |
Structure: |
Two Side Doors |
Transmission Type: |
Semi-Automatic |
Displacement: |
>400CC |
Product Description
Specifications
ENGINE Type: 700cc, Water cooled, 4-stroke, 1-cylinder, eec Atv, Sport Atv, 4wd Atv, Utility Atv, Raptor Atv, Epa Atv
Bore x Stroke: 102mm x 84mm
Compression Ratio: 9.1: 1
Ignition: CDI
Starting: Electric
Drive Train: Axle
Suspension/Front: Independent double swing arm
Suspension/Rear: Independent double swing arm
Brakes/Front: Dual ventilated hydraulic disc
Brakes/Rear: Ventilated Hydraulic disc
Tires/Front: AT25 x 8-12 radial
Tires/Rear: AT25 x 10-12 radial
L x W x H: 3000mm x 1850mm x 1400mm
Seat Height: 818mm
Wheelbase: 1910mm
Ground Clearance: 280mm
Fuel Capatity: 30L
Dry Weight: 526kg
Lighting: 12V35W/35W x 2(front); 12V. 5W/21W x 1(rear)
