Home Eagle Industry and Trade Co., Ltd. 260cc Water Cooled Shaft Drive EEC ATV /Quad (YG260E-A2)
260cc Water Cooled Shaft Drive EEC ATV /Quad (YG260E-A2)
| Price: | Negotiable |
|---|---|
| Min Order: | 1 |
Specifications
| Prod Model: | YG260E-A2 |
|---|
Product Description
KEY FEATURES:260cc, chunfeng WATER-cooled engine, 4 stroke, shaft drive, CVT with reverse gear, front/rear disc brake, EEC homologated
Specifications
Engine Type: 4 stroke, water-cooled, CVT
Final Drive: Shaft drive
Bore x Stroke(mm): 65 x 63
Piston Displacement(cc): 255cc
Compression Ratio: 9: 1
Maximum Power(kw/r/min): 12.5kw/7500r/min
Max Torque(N. M/r/min): 20.0N. M/5500r/min
Starter Sytem: Electric
Lubricaiton: Wet sump
Trasmission: C. V. T.
Overall LxWxH(mm): 2150x1212x1190
Packing Dimension LxWxH(mm): 2200x1250x860
Wheel Base(mm): 1265
Seat Height(mm): 865
Overall Height(mm): 190
Ground Clearance(mm): 100
Parking Brake: Hydraulic disc, all wheel
Brake(Front/Rear): Single lever hydraulic disc
Tire, Front: AT24x8-14
Tire, Rear: AT24x10-14
Ignition Type: CDI
Fuel Tank Capacity (L): 14
Front Suspension: Macpherson strut with 6in travel
Rear Suspension: Progressive rat swing arm with 7 intravel
Max Speed(km/h): 80km/h
Mini Turing Radium(mm): 3277
Max. Load Capacity(kg): 120
Battery Specifiction: 12V14Ah
NW(kg): 260
GW(kg): 310
Quantity of Loading: 27pcs 40'hq
