110CC ATV with EPA (TS-ATV110-E)

Specifications

Prod Model:	TS-ATV110-E

Product Description

ENGINE Type: Air cooled, 4-stroke
Displacement: 86cc, 107cc
Max Power: 4. 0kw/7500rpm
Max Torque: 5. 6Nm/6000rpm
Compression Ratio: 9. 1: 1
Lubrication: Pressure and Splash
TRANSMISSION: Stepless, automatic clutch, chain
Front/rear Supension: Double A-arm/ Swing arm
Rear brake: Rear Hydraulic disc
Front/rear Tyre: 16*8-7/16*8-7
DIMENSION(L*W*H)(mm): 1230*730*900
Seat Height: 640mm
Turn Radius: 1500mm
Ground Clearance: 105mm
Dry Weight: 65kg
Max Speed: 50km/h
Container: 120pcs/40'HQ
