Specifications
Product Description
Type / Displacement / ml Four-stroke, 284ml
Cylinders Single
Cooling Liquid
Bore & Stroke / mm 72x70
Ignition CDI
Rated Power and Rotate Speed 14 KW/6500r/min (19HP)
Max Torque and Rotate Speed 20 N.m/5800r/min
Exhaust Rear Exhaust
Clutch / Transmission V-belt CVT Automatic with reverse
Brake Type Rear Disk brake
Front Suspension Independent, Double A-arm
Ski Type steel
Overall Length / mm 2750mm
Overall Width / mm 1080mm
Overall Height / mm 1100mm
Track/Width x Length/mm 303x2852
Estimated Dry Weight 230kg
Ski Stance (ctr. to ctr.) in. 971mm
Fuel Capacity / L 12L
Fuel Type Regular Unleaded
Engine Oil Type #20
Electric Start Standard
Windshield Standard
Max speed 60 km/h
Warranty 1 Year (Limited Factory Warranty)
Loading:20':10 40':20 40HQ: 30
