Scooter (JL150T-12A)

Specifications

Prod Model:	JL150T-12A

Product Description

Overall Length(mm): 2210mm
Overall Width(mm): 685mm
Overall Height(mm): 1170mm
WheelBase(mm): 1450mm
Ground Clearance(mm): 140mm
Dry Weight(kg) 120kgs
Max. Load Mass(kg): 150kgs
Max. Speed(km/h): 90km/h
Tire: Front: 100/80-16 Rear: 110/80-16 or 120/80-16
Driving Mode: C. V. T
Brake Mode: Front: Disk Rear: Disk
Brake Operation Mode: Front: By Hand Rear: By Hand
Engine: JL157QMJ-3
Engine Type: Single Cylinder Four Stroke
Cylinder Type: Horizontal
Bore X Stroke(mm): Dia. 57.4 X 57.8mm
Piston Displacement(cc): 149.6cc
Compression Ratio: 9.2: 1
Max. Torque(N. M/rpm): 9.0/5000N. M/rpm
Lubrication: Compress & Splash Combined Type
Max. Output Power(kw/rpm): 7.0/8000kw/rpm
Ignition: C. D. I
Started System: Electric Starter/Kick Starter
Engine Cooling: Forced Air Cooling
Transmission: Stageless Transmission
Clutch: Dry\Multi-Disc Type
Battery: 12V-7Ah
Fuel Capacity(L): 7.1L
Packing: Carton with angle steel holder.
