Specifications
Prod Model: |
90R |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Cylinder Quantity: |
1 |
Fuel: |
Gas / Diesel |
Condition: |
New |
Certification: |
CE |
Starting System: |
Kick System |
Engine: |
4 Stroke |
Displacement: |
126-250CC |
Product Description
ENGINE
ENGINE TYPE single cylinder, 4-stroke
DISPLACEMENT 155.5CC
BORE/STROKE 60mm x 55mm
COMPRESSION RATIO 10.2: 1
STARTER Kick
TRANSMISSION Close Ratio 4 Speed Manuel Clutch
CARBURETOR 26mm
COOLING Oil Cooler
CLUTCH 5 plate wet clutch
GEARING 420/16T X 39T
CHASSIS
FRAME High Tensile steel specially shaped for pit bike strength
SUBFRAME Removable
HANDLEBAR Alloy, Fat bar 1 1/8", 760mm wide, knurled clutch side for secure grip hold
FRONT SUSPENSION 735mm length, 35mm inverted fork, adjustable
SUSPENSION TRAVEL FRONT/REAR 200mm Front/ 52mmRear
FRONT /REAR BRAKES 220mm front/190mm rear round-style Rotor W/ Floating Caliper
FRONT/REAR RIMS Alloy 7075, 1.40 x 14"/1.85 x 12"
FRONT/REAR TIRES 2.50 x 14"/3.0 x 12"
SWINGARM Progressive Link Tapered "D" Alloy and strengthen with niddle bearing, with linkage
WHEELBASE 1240mm Axle to Axle
GROUND CLEARANCE 290mm
SEAT HEIGHT 825mm
FUEL TANK CONTENTS 3.80 L
CURB WEIGHT 75kg
OVERALL LENGTH 1720mm
OVERALL WIDTH 750mm
