Home Shuopu Science and Technology Development Co., Ltd. Pitsterpro LXM 160R Motorcycle
| Prod Model: | 14 MOTARD |
|---|
Product Description
CHASSIS AND DIMENSIONSColor: WhiteFrame: Central Double Cradle Chromo W/ Tri Point Mounting, removable footpeg Design, Progressive Link
Fuel Capacity: 3.78 L
Ground Clearance: 12"
Overall Length: 69.5"
Overall Width: 31"
Seat Height: 33.5"
Subframe: Chromo Removable W/ Integrated Grab Handle
Swingarm: Progressive Link Tapered "D" Section Stamped Alloy W/ CNC Cross Section For Increased Rigidity, CNC Axle Blocks, Taper Axle
Wheelbase: 49" Axle to Axle
WHEELS AND TIRESFront Tire: 110/70-14"
Front Wheel: 1.85 x 14"
Rear Tire: 110/70-14"
Rear Wheel: 2.15 x 14"
HYRAULIC DISC BRAKESFront Brake: 220mm W-Style Rotor W/ Floating Caliper
Rear Brake: 190mm W-Style Rotor W/ Floating Caliper
Rear Pedal: Over the peg steel
SUSPENSIONFront: GPX Moto 35mm inverted forks w/ adj. Compression and rebound on each leg
Rear: GPX DNM Piggy Back reservoir w/ adj. Compression and rebound
Travel: 8" Front/ 10.6"Rear
ENGINEBore and Stroke: 60mm x 57mm
Carburetor: 26mm
Clutch: Five plate wet clutch
Compression Ratio: 10.2 to 1
Cooling: Air Cooled W/ Dual Oil Cooler
Engine: Four stroke GPX Moto 160CC SOHC air cooled
Gearing: 420/ 16T x 39T
Ignition: Outer rotor w/ lighting coil
Starter: Kick
Transmission: 4 Speed Manuel Clutch
