Specifications
Prod Model: |
125-S |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Wheel: |
Alloy |
Muffler: |
Alloy |
Meter: |
Digital |
Engine Type: |
4-Stroke |
Displacement: |
51-125CC |
Certification: |
CQC |
Type: |
Straddle |
Condition: |
New |
Fuel: |
Gas / Diesel |
Product Description
Basic Specifications:
Engine:
Zongshen 125cc single Manual clutch, Air Cooloer, 4 stroke, e/k-starter, non-rotary automatic gear
Or Zongshen W155cc single Manual clutch, oil-cooler, 4 stroke, e/k-starter, non-rotary automatic gear
Sprocket: Front 14 teeth, Rear 32 teeth
Shock Absorber: Yaoyong brand, Rear Mono Shock
Brake: Front Disk, Rear Drum
Wheel: Alloy
Tire: Front 80/90-17, Rear 100/80-17, WeiXing Brand
Muffler: Made of metal, round type with Muffler Cover
OR All Aluminium type
Meter: Digital type
Battery: 12V7A
Specifications
ENGINE TYPE: Zongshen, 4 Stroke, air cooler
DISPLACMENT (cc): 125cc
Or 155cc
CYLINDER: SINGLE
MAX. HORSEPOWER kw(r/min): 6.3 Kw / 7500 Rpm(125cc)
OR 10.5 Kw / 8500 Rpm(155cc)
MAX. TORQUE N. M(r/min): 8.8 Nm / 5500 Rpm(125cc)
OR 11.5 Nm / 6500 Rpm(155cc)
OVERALL L*W*H: 1940 * 940 * 1050
WHEELBASE (mm): 1290
DRY WEIGHT AMOUNT(kg): 102
TIRE STD. (FR/RR): 80/90-17 / 100/80-17
TYPE (FR/RR): DISK/ DRUM
HIGHEST SPEED (km/h): 90
CKD loading quantity 160 sets/40HQ
CBU loading quantity 105 units/40HQ
Engine |
Zongshen 125cc single Manual clutch, Air Cooloer, 4 stroke, e/k-starter, non-rotary automatic gear |
Zongshen W155cc single Manual clutch, oil-cooler, 4 stroke, e/k-starter, non-rotary automatic gear |
Sprocket |
Front 14 teeth, Rear 32 teeth |
Front 14 teeth, Rear 32 teeth |
Shock Absorber |
Yaoyong brand, Rear Mono Shock |
Yaoyong brand, Rear Mono Shock |
Brake |
Front Disk, Rear Drum |
Front Disk, Rear Drum |
Wheel |
Alloy |
Alloy |
Tire |
Front 80/90-17, Rear 100/80-17, WeiXing Brand |
Front 80/90-17, Rear 100/80-17, WeiXing Brand |
Muffler |
made of metal, round type with Muffler Cover
|
All Aluminium type
|
Meter |
digital type |
digital type |
Battery |
12V7A |
12V7A |
|
|
|
CKD loading quantity |
160 sets/40HQ |
160 sets/40HQ |
CBU loading quantity |
105 units/40HQ |
105 units/40HQ |
|
|
|
specification |
|
|
|
125cc |
155 |
ENGINE TYPE |
Zongshen, 4 Stroke, air cooler |
Zongshen, 4 Stroke, oil-cooler |
DISPLACMENT (cc) |
125cc |
155.5 |
CYLINDER |
SINGLE |
SINGLE |
MAX.HORSEPOWER kw(r/min) |
6.3 Kw / 7500 Rpm |
10.5 Kw / 8500 Rpm |
MAX.TORQUE N.m(r/min) |
8.8 Nm / 5500 Rpm |
11.5 Nm / 6500 Rpm |
OVERALL L*W*H |
1940 * 940 * 1050 |
1940 * 940 * 1050 |
WHEELBASE (mm) |
1290 |
1290 |
DRY WEIGHT AMOUNT(kg) |
102 |
102 |
TIRE STD.(FR/RR) |
80/90-17 / 100/80-17 |
80/90-17 / 100/80-17 |
TYPE (FR/RR) |
DISK/ DRUM |
DISK/ DRUM |
HIGHEST SPEED (km/h) |
90 |
120 |
