Specifications
| Prod Model: | QH110-2A(110Engine)/QH100-2A(100Engine) |
|---|
Product Description
1) Dimensions(L x W x H): 1896x 705x 10802) Wheelbase: 1225mm
3) Net weight: 92kg
4) Max. Load: 150kg
5) Max. Speed: 80km/h
6) Engine type: Single cylinder, air-cooled, 4-troke
7) Displacement: 107mm/97mm
8) Cylinder work capacity: 49. 5ml
9) Compression ratio: 8. 8: 1
10) Starter system: Automatic Electrical /kick
11) Lubrication: Pressure/splash
12) Ignition type: C. D. I
13) Standard Power: 4.4/8000kW/r/min
14) Max. Torque: 6.5/6000N. M/r/min / 6.2/6000N. M/r/min
15)Bore x stroke mm: 52x 49.5
16) Tyre Size(Front /Rear): 2.50-17-6PR/2.75 17-6PR
17)Brake type(Front /Rear): Disk/Disk
18)Idle speed r/min: 1500
