Specifications
Product Description
Main weight data
ITEM UNIT TECHNICAL DATA
Dry weight kg 113
Load weight kg 126
Rated Max. Loading kg 150
Main performances
Horn Grade dB (A) 93~112
Reliability km 6000
Wear km 20000
Main structure type and technical parameter
Name of parts Item Type/technical parameter
Engine
Engine model 162FMJ
Engine type Single-cylinder, 4-stroke, air-cooled
Start type By Electric/kick start
Ignition type C. D. I
Diameter of cylinder (mm) 62.0
Stroke of piston (mm) 49.5
Capacity of cylinder (ml) 149.4
Compression ratio 9.0: 1
Rated power and relative rotate speed (kw/r/min)8.5/9000
Max. Power and relative rotate speed (kw/r/min)10.0/9500
Max. Torque and relative rotating speed (kw/r/min)10.0/7500
Min. Speed when empty load (r/min) 1420
Min. Fuel consumption rate (g/kw. H) less than 354
Fuel No. Above RQ-90
Lubrication oil No. 15W/40
