Specifications
Prod Model: |
CF 140 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Starting System: |
Kick System |
Engine: |
4 Stroke |
Displacement: |
126-250CC |
Product Description
Engine single cylinder, 4-stroke
Displacement 140CC
Bore/stroke 56mm x 57mm
Compression ratio 8.8: 1
Starter kick
Transmission close ratio 4 speed manual clutch
Carburetor 24mm
Cooling CNC oil cooler
Clutch 5 plate wet clutch
Gearing 20/15t x 39t
Frame chromoly frame with engine cradle
Subframe chromoly removable
Handlebar steel standard style, 760mm length
Front suspension 735mm length, 33mm invert fork, nonadjustable
Suspension travel front/rear 190mm front/ 52mm rear
Front /rear brakes 210 mm front/190mm rear round-style
Rotor w/ floating caliper
Front/rear rims steel, 1.40 x 14"/1.85 x 12"
Front/rear tires 2.50 x 14"/3.0 x 12"
Swingarm alloy
Wheelbase 1160mm axle to axle
Ground clearance 254mm
Seat height 787mm
Fuel tank contents 3.78l
Curb weight 65kg
Overall length: 1675mm
Overall width: 810mm
