Specifications
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Usage: |
Electric Tool |
Speed: |
Constant Speed |
Starting Mode: |
Capacitor-start-and-run Single Phase Asynchronous Motor |
Power Source: |
AC Motor |
Structure: |
Synchronous Motor |
Function: |
Driving |
Product Description
Overall Dimentions (LXWXH): 1067X483X940 mm
Weight without battery: 30 kgs
Max Speed: 6.4 km/h
Braking: 0.6 m (Dry Surface)
Max Climbing slope: 8 degree
Ground Clearance: 35 mm
Weight Capacity: 120 kgs
Motor Rated Power: 24V 180W
Controller: 24V 45A
Battery Charger: 2A
Batteries: 2 PCS of 17AH
Battery Weight: 11.4 kgs
Braking System: Electric Regenerative
Braking
Front Tire: 8"X2" Pneumatic
Rear Tire: 8"X2" Pneumatic
Seat Type: Small
Seat color available: Black
Seat Size (LXWXH ): 380X420X36(42) mm
Seat Weight: 7kgs
Container packing: 87 PCS / 20 GP`
181 PCS / 40 GP`
203 PCS / 40 HQ`
Range per Change: 30 km
