Home Ningbo Andorra Import and Export Co., Ltd. Fashion 125cc Cub Motorbike
Fashion 125cc Cub Motorbike
| Price: | US $ 300-400SET |
|---|---|
| Trade Terms: | FOB |
| Min Order: | 1x20'FT |
| Pay Type: | T/T |
Specifications
| Prod Model: | KG135B-ID |
|---|---|
| Markets: | South America,Africa |
| Brand: | Kyngo |
| Normal Color: | Red/Black/White/Blue/Gray |
| Type: | Cub Motorcycle |
| Engine Type: | 4-Stroke |
| Fuel: | Gas / Diesel |
| Certification: | CE |
| Condition: | New |
| Displacement: | 51-135cc |
| Braking Mode: | Front & Rear Drum Brake |
Product Description
FASHION 125CC CUB MOTORBIKEProduct Instructions:
1. 125cc engine, Single Cylinder, 4-stroke, Air Cooling
2. normal double back shock absorber
3. spoke rim, rim size: Front 1.4×17,rear 1.6×14
4. Normal tires, front: 2.25-17, rear: 2.75-14
5. Normal folding pedal, black painted muffler.
6. Brake: front/rear drum
7. steel black painted back armrest
8. Leather seat in car body color
9. Large space below seat, can place 1 adult helmet
10. With alarm, NEW speedometer
11.cute car body, easy use, more safety
12.brand sticker and colors can be customed
1.Packaging:
2. Delivery: 30 days after the receipt of the deposit
3. Payment: T/T 30% deposit in advance, 70% balance against the copy B/L
4. SHIPPING: BY SEA
TECHNICAL DATA:
1.Packaging:
Form1 CBU/SKD packing: Steel Cage+ Standard Export Cartons
Form 2 CKD packing: engine used carton packing and be separated to the body part. Body parts are packaged with carton or with plywood box one unit by one package.
2. Delivery: 30 days after the receipt of the deposit
3. Payment: T/T 30% deposit in advance, 70% balance against the copy B/L
4. SHIPPING: BY SEA
TECHNICAL DATA:
| Engine | |
| Displacement (ml): | 135cc |
| engine model No | 154FMI |
| engine type | Single Cylinder/Horozail/Air cooling |
| brake type | Front/Rear:drum brake |
| start type | Electric/kick start |
| bore*stroke(mm) | 54*55.5 |
| compress ration | 8.7:1 |
| standard power(kw/r/min) | 6.4KW/8000±500r/min |
| Max torque(N.m/r/min) | 9.5N.m/5500±500r/min |
| tyire size | Front:2.25-17-6PR Rear;2.75-14-6PR |
| climb(°) | ≥18° |
| start type | C.D.I |
| clutch type | Manual Clutch |
| lubrication | Pressure Splash |
| lubrication oil vol(L) | 0.9 |
| valve gap(mm) | In:0.03,Out:0.05 |
| DIMENSIONS | |
| dimension(mm)L*W*H | 1900×700×1090mm |
| brake distance(m) | ≤7m(30Km/h) |
| wheel base(mm) | 1280mm |
| ground distance(mm) | ≥120mm |
| start time(s) | ≤15s |
| standard loading(Kg) | 150 |
| N.W(Kg) | 96 |
| Max speed(km/h) | 81 |
| min fuel cons.(L/100km) | ≤2.1 |
| seat height(mm) | 770 |
| fuel tank vol(L) | 4.6 |
| fuel size | 90# |
| spark sixe | D8RTC |
| spark gap(mm) | 0.6~0.7 |
| loading quantity(40HQ) | skd packing 105sets/40HQ |
FAQ
1. Can I order sample?RE: Yes, we accept sample for trial order.
2. How long for delivery time?
RE: For sample order, our delivery time is 20 to 25 days; for one full container, it's 30days.
3. Which color & decals will be available?
RE: Normally, we will introduce the most popular color & decals to customer selection. And we also can design decals according the customer's requirement.
4. Can I use my logo (sticker) on the motorcycle?
RE: Yes, we can do OEM
5. How to delivery to foreign buyer?
RE: For sample order, the customer can select by sea or by air. For full container order, by sea is the best choice.
6. What's the payment term?
RE: Normally we use T/T
7. Can I mix different models in one full container order?
RE: Yes, for first order, we can accept different models in one full container for trial.
8. Need I buy spare parts for first order?
RE: yes, you need to buy some spare parts for future service, The quantity depends on your order. We will give you advice when you need. normally, we can supply 1 set wearing parts for free.
