Specifications
Prod Model: |
KG135-NF |
Markets: |
South America,Africa |
Normal Color: |
Red/Blue/Gray/Champagne/Black |
Brand: |
OEM & ODM |
Type: |
Cub Motorcycle |
Engine Type: |
4-Stroke |
Fuel: |
Gas / Diesel |
Certification: |
CE |
Condition: |
New |
Displacement: |
110-135cc |
Engine Size: |
110-135ml |
Braking Mode: |
Front Disc Rear Drum Brake |
Product Description
135CC CUB MOTORCYCLETechnical data: |
|
Engine | Single Cylinder, 4-stroke, Air Cooling Engine |
Displacement | 135ml |
Max Power | 6.5kw/7500±500r/min |
Max Torque | 8.6N·m/5500±500r/min |
Compression Ratio | 9.0:1 |
Ignition | CDI |
Start | Electric/Kick Start |
Transmission | 4 Speed Manual |
Clutch | Automatic Clutch |
Lubrication | Pressure Splash |
Dimension | 1960×690×1140 mm |
Wheel Base | 1310 mm |
Weight | 93kg |
Max Load Capacity | 150kg |
Max Speed | 85km/h |
Tyres | Front 2.25-17, Rear Drum 80/100-14 |
Brakes | Front Disc, Rear Drum |
Battery | 12V 5A·h |
Loading Information | Capacidad |
| 40′HQ |
CBU | 90 |
CKD | 120 |
Main Instructions:
1. 135cc engine, Single Cylinder, 4-stroke, Air Cooling
2. Normal double back shock absorber
3. Aluminum rim, rim color can match body color
4. Aluminum folding pedal
5. Aluminum back armrest, Chromeplate black painted muffler.
6. Leather seat, more comfortable
7. Large space below seat, can place 1 adult helmet
8. with remote alarm
9. This model is very popular in South America with its superior performance and fashionable style.
10. competitive price\good delivery\high quality.
11.Safe, Charming, Reliable cub motorcycle made for gentlemen
12. We support OEM, ODM, SKD, CKD or whole parts form and support customers' Logo and stickers.
