Specifications
Prod Model: |
hammerhead 500cc |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Start-up: |
Electric |
Transmission: |
Shaft |
Displacement: |
>400CC |
Certification: |
EEC |
Product Description
Product dimension: 2850*1600*1500mm
Engine: CF188, 1-cylinder, 4-stroke, water-cooled
Displacement(ml): 498
Ignition: CDI
Start mode: Electric-start, 12V
Transmission type: Automatic CVT (R/N/H/L)
Drive Mode: Shaft drive, selectable 4x2 / 4x4
Maximum Power: 32.6HP
Fuel Capacity (L/gal): 32/7.04
Max. Speed: < 90 km/h
Wheelbase: 2195mm
Min. Ground Clearance: 350mm
Suspension System: F. Double spring suspension/R. Double wishbone
Brake type: F. Dual disc brake/R. Dual disc brake
Tire/Wheel Size: Ft: 25 x 8-12, Rr: 25x10-12
Dry Weight: 520kg
Packing size: 2.64*1.54*1.10 m for 20'gp.
/ 2.64*2.02*0.86 m for 40'HQ
Conveyance: 4pcs/20'gp, 12pcs/40'HQ
