Cub Motorcycle (SJ110-16A)

Specifications

Prod Model:	SJ110-16A

Product Description

Feature: 110cc. 4 stroke, electric&kick start, automatic clutch, front disc&rear drum, spoke wheel, rear view mirror, single arm rest.
Specifications:

Engine type: Single cylinder, air cooling, 4 stroke
Clutch: Automatic
Ignition method: C. D. I.
Start method: Electric&kick

Cylinder: Single
Transmission: Chain
Displacement(ml): 107
Bore*stroke(mm): 52.4*49.5
Compression ratio: 8.8: 1
Lubrication: Splash
Gear: 4
Dimensions(L*W*H)(mm): 1970*680*1100
Wheel base(mm): 1260
Seat height(mm): 780
Min. Turning radius(mm): 1900
Min. Ground clearance(mm): 130

Rider capacity: 2
Brake: Front disc&rear drum
Front wheel: 2.50-17
Rear wheel: 2.75-17
Fuel tank capacity(L): 4.5
Engine oil capacity(ml): 800
Max. Load(kg): 110
Max. Speed(kw/h): 75
Battery: 12V9B
Packing size(L*W*H)(mm): 1680*450*810
Net weight(kg): 96
Gross weight(kg): 115
