Specifications
| Prod Model: | JLA-22A EEC |
|---|
Product Description
1. Engine type: 196CC/248CC, 4 storke2. Bore and stroke 63.5x62.2/72x62.2
3. Compression rating: 9.2: 1
4. Max torque: 13.5Nm/5500rpm, 17.5Nm/5000rpm
5. Max power: 10kw/7500rpm, 11kw/7500rpm
6. Ignition type: CDI
7. Transmission: Manual clutch, 4-speed, reverse gear, shaft drive
8. Brake (Front/Rear): Drum/Drum
9. Starting system: Electric start
10. Battery spec: 12V, 9AH
11. Front suspension details: Double A x swing arm,: Air chamber shock absorbers
12. Rear suspension details: Mono shock swing arm
13. Front tire spec: 23 x 7-10
14. Rear tires spec: 22 x 10-10
15. Vehicle dimensions: 185x104x113cm
16. Wheel base: 1160mm
17. Seat height from ground: 90cm
18. Ground clearance: 155mm
19. Load capacity: 165kg
20. Fuel tank capacity: 11L
21. Gross weight in carton: 240kg
22. Net weight: 220kg
23. Packing size: 197x111x88cm
Conveyance:
Qty/20' GP: 12 units
Qty/40' GP: 24 units
Qty/40' HQ: 36 units
