ATV (GATV150S)

Specifications

Prod Model:	GATV150S

Product Description

Main parameter as well as function index

Length x Width x Height (mm): 1520 x 890 x 1050

Wheel Base(mm): 1010

Engine Type: Single Cylinder; Air-cooling; #12288; Four stroke

Start Mode: Electric/Electric kick

Power (Kw/r/min): 5.2/7500r/min

Max Torque (N. M/r/min): 8.4/6500r/min

Mini Ground Clearance (mm): 110

Max Speed: >=45

Dry Weight(Kg): 130

Transmission Mode: Chain

Break Type(F/R): Type of hydraulic pressure after the previous drum

Specification: 12V 7 Ah

Climb Degree: >=20

Tank Capacity (L): 3.4L

Front Hanging: #12288;

Rear Hanging: Integral

Specification of tyre: Front-wheel drive 19 x 7-8; #12288; Rear whee l18 x 9.5-8

Cylinder Diameter*Journey(mm): 57.4 x 57.8

Displacement (ml): 149.65

Shift Gear: CVT

Height of seats(mm): 680

Mini Turning radium(mm): 2500

Parking Trig: Mechanic Lock

Ignition Mode: C.D.I

Loading Capacity(kg): 125

Engine Oil (L): 0.9

Gear Wheel oil (L): 0.1

Person: 1

Lubrication: Press Splash

Compression Proportion: 9.1: 1

Gas Cylinder number: #12288;

Parking Dimension(mm): 1510 x 920 x 770

Quantity of loading 20"GP: 21 units

40'GP: 45 units
40'HQ: 45 units
