Specifications
Product Description
Engine Type: 4-Strokes, Air Cooled, with reverse gearCylinder Arrangement: Single Cylinder
Transmission System: Shaft Drive
Bore x Stroke (mm): 52. 4 x 49. 5
Piston Displacement (cc): 107
Compression Ratio: 9. 1: 1
Maximum Power (kw/r/min): 5. 5/8000
Maximum Torque (N. M. /rpm): 6. 5/5750
Starter System: Electric Starter
Lubrication: Auto
Transmission: 3 Speed, Semi Automatic
Overall Length (mm): 1760
Overall Width (mm): 950
Overall Hight (mm): 830
Wheel Base (mm): 1040
Seat Hight (mm): 700
Min. Turning Radius (mm): 2400
Ground Clearance: 100
Rider Capacity: 1 Person
Dry Weight (kg): 130
Brake (Front/Rear): Drum/drum
Tyre, Front: 19x7-8/2. 9Psi
Tyre, Rear: 12288; 18x9. 5-8/2. 9psi
Ignition Type: C. D. I.
Fuel Tank Capacity (L): 6
Engine Oil Capacity (L): 0. 95
Gear Oil Capacity (L): 0. 12
Front Suspension: Swing Arm
Rear Suspension: Monoshock Swing Arm
Parking Brake: Mechanical Lock
Max. Load Capacity (kg): 95
Max. Speed: 50
Battery: 12V-9Ah
20`/40HQ` QTY., CONTAINER: 21/66 units
(disassembled 4 wheels, wheel don`t be packed in bike`s package )
