Specifications
Prod Model: |
JH3270 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Power: |
7HP |
Gears: |
5 Forward&2 Reverse |
Chute Rotating Angle: |
190 Degree |
Cylinders: |
1 |
Engine: |
4 Stroke |
Displacement: |
200CC |
Product Description
Certificates: CE, EPA, CARB, EURO-2
Power supplier: 7HP(5.25Kw)
--Displacement: 212CC
--Engine: LC170, 4 stroke, OHV, air-forced cooling, single-cylinder, gasoline
--Fuel tank capacity: 3.6 L (0.95 US gallon)
--Oil tank capacity: 0.6L
--Operational Capacity per tankful (approx. ): 3.5hours
--Max. Working load: 1600lbs/minute(theoretical)
Max. Throwing distance: 10-15m (theoretical)
Max. Working width: 22"(56cm)
Max. Working depth: 20"(51cm)
Chute rotating angle: 190 Degree
Type of transmission: Friction disc
Gears: 4 Forward & 2 Reverse
Type of wheels: 13''snow hog tyre
Light: Asymmetric halogen lighting
Start type: Recoil start/ Recoil & Electrical starter
N. W/G. W: 80/90 kg
Packing Dimension: 91 x 64 x 71(cm)
Conveyance: 63PCS/20'GP; 132PCS/40'GP.
