Product Description
1) Max. speed: 30km/h
2) Max. range: 70km
3) Max. load: 80kg
4) Engine: single-cylinder, 4-stroke, air-cooled
5) Displacement: 49cc
6) Rated power and rotate speed: 2.3kW / 8,500rpm approx.
7) Max. torque and rotate speed: 2.7N.m / 6,500r/min
8) Start: kick and electric
9) Fuel tank: 3.4L
10) Compressing ratio: 7:1
11) Transmission: fully-auto clutch and 4-speed semi-auto
12) Wheel: 145 x 70-6
13) Brake: disc
14) Suspension front: hydraulic rear
15) Mounting: 15 degrees
16) Distance between axles: 690mm
17) Distance between front wheels: 420mm
18) Distance between rear wheels: 510mm
19) Ground clearance: 110mm
20) Product dimensions: 112 x 73 x 56cm
21) Colors available: red, blue, black, yellow, green
Outer packing:
1pc/ctn
Carton dimensions: 115 x 76 x 70cm
N.W.: 19kg
G.W.: 22kg
Conveyance:
Qty/20' FCL: 51pcs
Qty/40' FCL: 102pcs
Qty/40' HQ: 128pcs
Kingspirits Industry Co., Ltd. is a professional manufacturer& exporter of ATV, Dirt Bike, Scooter, Go Kart, Auto Parts and accessories. We established in 2000. Combining electronic and mechanical technologies, we can supply over 50, 000 complete vehicles and 200, 000 accessories annually. Our factory covers an area of 150, 000 square meters with $15 million in fixed assets and more than 3, 000 employees.
We are aimed to "Quality and Reputation is the most important, Customer is the God, Service is foremost", we also provide good quality guarantee to clients. Rely on excellent equipment, high quality, strict control system, and are far sold to America, France, Germany, England, Japan, Spain, Sweden, ect., almost 20 countries all over the world.
