Product Description
Engine Type Single Cylinder, Air cooled, 4-Stroke, SteplessTransmission System: Chain Drive
Bore× Stroke(mm): 37X41
Displacement(mm): 49
Max Power(Kw/r/min): 2.4/5900
Max Torque: 3.9/5500
Starting system: Electric
Transmission: Automatic
Seat height(mm): 542
Min Turning Radius(mm): 1500
Ground Clearance(mm): 110
Wheel Base(mm): 830
Brake(Front/Rear): Drum/Disc
Front Tyre: 16X7-8
Rear Tyre: 16X7-8
Ignition Type: CDI
Fuel Tank(L): 3.2
Battery: 12V-4Ah
Parking brake: Mechanical Lock
Pay load(Kg): 45
Net weight(Kg): 74
Rider capacity: 1 Person
L*W*H: 1335*730*780
LONGTING Company is equipped with the most advanced techniques of developing and manufacturing CROSSBIKE and ATV, one advanced assembling and packing process assembly line, two specific testing assembly lines and devices. The products are manufactured strictly by the level of ISO9001 and the annual output is 50000 sets. The company is one of the professionally export-oriented enterprises in Chongqing. Its core markets have been widely promoted in the USA, the UK, Spain, France, Germany, Australia and South Africa, etc. The series of ATV are ATV50, ATV90, ATV110, ATV125, ATV150, ATV200 and ATV250, as well as CROSSBIKE including PY50, PY80, PY90 and PY110, GK250. Currently, the company is developing ATV with larger displacement.
