Specifications
Product Description
Description: Shaft drive; Reverse, five speed; Electrical start;
Engine: Two Exhaust Pipe/Fore Stroke, 299CC
Overall Dimension L*W*H 1900mm*1050mm*1160mm Cylinder dia...*Working stroke 78mm*61.2mm
Ground clearance 120mm Efficient Capacity 292ml
Max Speed ≥80km/h Rated Power and Rotate Speed 16. 8KW/7500r/min
Climbing Ability ≥20 Max Torque and Rotate Speed 20N. M/6000r/min
Specification of Front wheel 22*7-10/21*8-10(on road) Compressing Ratio 8.9: 1
Specification of Rear wheel 22*10-8/22*10-10(on road) Gearshift Mode Five Speed/Reverse
Brake system front/rear Drum/Disk Transmission Shaft Drive
Starting System Electric Packing Size 1700mm*1150mm*1150mm
Cooling System Air Cooling Net weight 220KG
Fuel tank 7.5L Gross weight 250KG
