Product Description
Engine Type 4-Stroke, Single Cylinder, Air cooled, Fully- automaticTransmission System: Shaft Drive
Bore× Stroke(mm): 71X58
Displacement(mm): 229.6
Max Power(Kw/r/min): 10/6000-7000
Max Torque:15/5500-6500
Starting system: Electric/Recoil backup
Transmission: 5 Speed, semi-automatic
Engine Oil(L): 1.6
Gear Oil(L) 0. 27
Seat height(mm): 810±20
Min Turning Radius(mm): 2900
Ground Clearance(mm): 155
Brake(Front/Rear): Drum/Drum
Front Tyre: At23X7-10
Rear Tyre: At22X10-10
Ignition Type: CDI
Fuel Tank(L): 12
Front Suspension: Independent Front Suspension
Front Suspension: Swing Arm
Battery: 12V-14Ah
Parking Brake: Mechanical Lock
Pay Load(Kg): 165
Net Weight(Kg): 220
Rider Capacity: 1 Person
Wheel Base(mm): 1160
Lubrication: Pressing Splash
Overall Length(mm) 1940
Overall Width(mm) 1050
Overall Height(mm) 1160
LONGTING Company is equipped with the most advanced techniques of developing and manufacturing CROSSBIKE and ATV, one advanced assembling and packing process assembly line, two specific testing assembly lines and devices. The products are manufactured strictly by the level of ISO9001 and the annual output is 50000 sets. The company is one of the professionally export-oriented enterprises in Chongqing. Its core markets have been widely promoted in the USA, the UK, Spain, France, Germany, Australia and South Africa, etc. The series of ATV are ATV50, ATV90, ATV110, ATV125, ATV150, ATV200 and ATV250, as well as CROSSBIKE including PY50, PY80, PY90 and PY110, GK250. Currently, the company is developing ATV with larger displacement.
