200cc EEC Racing ATV Gt200st-B
| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB |
| Min Order: | 10/Piece |
| Pay Type: | L/C,T/T,Western Union |
| Prod Model: | GT200ST-B |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Transmission System: | Chain Drive |
| Transmission Type: | Manual |
| Certification: | EEC |
| Engine Type: | 4 Stroke |
| Fuel: | Gas / Diesel |
| Displacement: | 200CC |
| Structure: | Without Door |
| Brake Type: | Disc Brake |
| Maximum Speed: | 70km/H |
Product Description
200CC EEC Japan GENATA ATV / Racing ATV / quad bike (GT200ST-B)EEC No.: e4*2002/24*2015*00
| ENGINE | |
| Type: | Single cylinder,water-cooling,4-stroke |
| Cylinder size (mm): | 63.5×62.2 |
| Displacement (ml): | 197 |
| Ignition mode: | CDI |
| Compression proportion: | 9.2:1 |
| Power (kw/r.mi): | 9.5/7500 |
| Max. Torque (N.m/rpm): | 12.1/6000 |
| Engine oil(L): | 0.9 |
| Lubrication: | Press splash |
| Start mode: | Electric recoil backup |
| CHASIS | |
| Transmission mode: | Chain |
| Transmission: | 4 gears with one reverse gear,manul clutch |
| Max. Speed (km/h): | ≥70 |
| Power source: | 12V/9Ah |
| Parking trig: | Mechanical lock |
| Brake type (F/R): | Disc/disc |
| Front hanging: | Double arm-swing |
| Rear hanging: | integral |
| DIMENSION | |
| Wheelbase (mm): | 1230 |
| Front wheels: | 21×7-10 |
| Rear wheels: | 20×10-9 |
| Heights of seats (mm): | 850 |
| Dry weight (kg): | 167 |
| Load capacity (kg): | 105 |
| Climbing degree: | ≥20º |
| Min. Ground clearance (mm): | 130 |
| Min. Turning radius (mm): | 2650 |
| Max. Number of riders: | 2 |
| Fuel tank capacity (L): | 5.5 |
| PACKAGING | |
| Product dimensions (mm): | 1740×1110×1110 |
| Carton dimensions (mm): | 1470×850×870 |
| Product colors: | Red/yellow/blue/green/camouflage |
| Conveyance: | 20' GP:20units 40' GP:44units 40' HQ:66units |
Chongqing Beyond Special Vehicle Limited is one of the subsidiaries of GENATA group, which is a professional manufacturer of ATVs series, Go karts, Motorcycle, and power equipments. We specialize in the production of the former products and are experienced in sales and services with a well-staffed research and development department.
We has established a production and research and development base in Chongqing and Zhejiang. The current production area covers over 50, 000 square meters, with over 300 well-qualified and efficient engineers and technicians. More than 50 affiliated factories are engaged in the production of spare parts and accessories while the sales outlet is in HongKong. The sales head quarter and customer service centre has been moved to Guangzhou recently to serve clients all over the world.
Our company adopts the most advanced technology in the production of ATVs, go karts, and power equipments under the close supervision of our Japan Head Quarter. Moreover, our factory is equipped with advanced assembly lines, packing process assembly lines and specific testing assembly lines. With a high standard of Quality Control, our factory has attained the International Standard of ISO 9001, as well as ISO 9001: 2000 for Inter-national Management System.
The motto of Genata is: "To serve people with the best quality ". We will endeavour to produce high quality products to cater for the needs of clients all over the world.
We has established a production and research and development base in Chongqing and Zhejiang. The current production area covers over 50, 000 square meters, with over 300 well-qualified and efficient engineers and technicians. More than 50 affiliated factories are engaged in the production of spare parts and accessories while the sales outlet is in HongKong. The sales head quarter and customer service centre has been moved to Guangzhou recently to serve clients all over the world.
Our company adopts the most advanced technology in the production of ATVs, go karts, and power equipments under the close supervision of our Japan Head Quarter. Moreover, our factory is equipped with advanced assembly lines, packing process assembly lines and specific testing assembly lines. With a high standard of Quality Control, our factory has attained the International Standard of ISO 9001, as well as ISO 9001: 2000 for Inter-national Management System.
The motto of Genata is: "To serve people with the best quality ". We will endeavour to produce high quality products to cater for the needs of clients all over the world.
