Specifications
Prod Model: |
HL-A412 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Color: |
Red, Black, White |
Fuel: |
Gas / Diesel |
Certification: |
CE |
Transmission System: |
Chain Drive |
Engine Type: |
4 Stroke |
Structure: |
Two Side Doors |
Transmission Type: |
Automatic |
Displacement: |
200CC |
Product Description
Engine: 200cc, Single Cylinder, 4 Stroke, Forced Air-cooled
Start Mode: Electric start
Transmission: Chain drive
Engine Displacemnet(ml): 249
Shift Speed Type: Five, With Reverse Gear
Brake system: Front two disc brake, rear single disc brake
Brake Distance(m/30km): 7
Fuel Tank capacity: 5.5L
Clutch Mode: Manual
Bodywork: ABS plastic
Reverse gear: Yes
Length X Width X Height(mm): 1590x870x990
Minimum Turning Radius(mm): 3000
Climbing Degree: 35
Lamp: Head Lamp
Seat Height(mm): 670
Minimum Ground Clearance(mm): 120
Top Speed(Km/h): 75
Bore x Stroke: 68.5mm x 62.2mm
Max Power(km/r/min): 12/7500
Max Touque(r/min): 15/6000
Tire Dimension(Front/Rear): AT19*7-8/AT18*9.5-8
Wheel hub: Steel
Carton dimensions: 1480 x 850 x 780mm
G. W.: 155KG / N. W.: 130KG
Container: 30pcs/20ft; 66pcs/40ft
