110CC Mini Utility CE ATV (ATV-S110NF)

Specifications

Prod Model:	ATV-S110NF

Product Description

Engine: 110cc, air-cooled, 1-cylinder
Actual displacement: 107ml
Bore*Stroke: 52.4 X 49.5mm
Compression ratio: 9.1: 1
Rated power: 4.7kw/8500r/min
Max Torque: 6.5N. M/6000r/min
Starting mode: Electric
Ignition mode: CDI
Transmission: Chain
Gearshift mode: 3 gears with reverse
Product size: 1320*70*80mm
Wheelbase: 860mm
Tire tread: Front 780mm rear: 823mm
Min. Ground clearance: 80mm
Rated loading capacity: 200kg
Fuel tank capacity: 6.5L
Front & rear shock absorber: Hydraulic
Tire: Front: 19*7.00-8
Rear: 13*5.00-6
Net weight: 107.5kg
Gross weight: 142kg
Packing size: 136.5*94*75cm
FCL quantity: 30PCS/20'GP, 60PCS/40'GP, 60PCS/40'HC

Option (not free): With trailer
