Home Fukang Motorsports Co., Ltd. Go kart 300CC Eagle II 300
Specifications
| Prod Model: | EAGLE II 300 |
|---|
Product Description
Fonkon Motorsports2007 new range 300cc gokart.
Model: Eagle II 300
Detail Specification:
EAGLE 300 Gokart Basic Technical Parameter
Gategory Item Parameter
Dimension Dimension(LxWxH) 2305x1330x1480mm
Seat Height 480mm
Wheelbase 1650mm
Front Track 1360mm
Rear Track 1280mm
Ground Clearance 205mm
Engine Type Single, 4-stroke, Water-cool, OHV
Model XD178MN
Bore x Stroke 78mmX60mm
Displacement 286. 7ml
Compressive Ratio 10. 2: 1
Max. Power & RPM 15kw/7000r/min
Max. Torque & RPM xxxxx/5500r/min
Min. Unloading RPM 1500 +/-100r/min
Min. Gas consumption less than 340g/kwh
Engine Rotate Direction Counter clockwise (output power plug)
Ignition C. D. I
Lubrication Force & Splash
Starting Electric
Quality Unloading Weight 315kgs
Transmission Clutch Automatic of axis
Transmission CVT
Tire Front Wheel 19 X 7 -8
Rear Wheel 20 X 10 -10
Tire Pressure Front Wheel 1. 0BAR
Rear Wheel 1. 0BAR
Accessory Carburetor Constant vacuum diaphragm
Spark Plug DPR7EA-9(NGK)
Muffler Silencer Impact Resistant
Air Box Paper Element
Battery 12V 9Ah
Gas Tank Capacity L 12L
Gas Brand 90# No Lead
Lubricate Brand SEA15W/40/SF
Coolant Specification Freezing Point: -35ºC Boiling Point 109. 6 ºC
Item Unit Guideline
Top Speed km/h 80
Starting Performance s ≤15
Brake Distance m 7
Climbing 25%
Limits and measurement of noise Db(A) 80
Emission of pollutants Idle Speed (CO) CO% 4
(HC) HC(ppm) 1000
Visible grain objects should never be released under any condition
Initial Accelerate s 100m 11s
Contact with us for more information.
