Specifications
| Prod Model: | 650cc |
|---|---|
| Certification: | EEC |
| Displacement: | >400CC |
| Transmission Type: | Automatic |
| Engine Type: | 4 Stroke |
| Transmission System: | Shaft Drive |
Product Description
Character:Automatic & Semi-Automatic Transmission
4 & 2 Wheel Drive Selectable
Front/Rear Disc Brake
Independent Suspension
Digital Instrument
Stainless Steel Exhaust system
Maintenance-free Battery
Water Cool System
Front/Rear Axle Drive
Packing :Carton with Iron Frame
Dimension(LxWxH):2750x1450x1850(100.4x53x72.8 in.)
N.W.:540KGS G.W.: 620KGS
4 units for 20FT container
12 units for 40FT container
| Main Parameter | ||||||||
| Engine | Type: Dual-cylinder,four-stoke,water-cooled,CDI | Displacement: 644cm 3 (650cc) | ||||||
| BorexStroke: 76x71mm(2.99x2.79in) | Compression: 9.0:1 | |||||||
| Max power output: 24 kw | Max torque: 49N.M | |||||||
| Chassis | Front tire size: AT25x8-12 | Rear tire size:AT25x10-12 | ||||||
| Electrical | Battery: 36Ah,12V | |||||||
| Instrument | Speedometer: Metric system/British system for operation | |||||||
| Capacity | Turning Radius: <40000mm | Fuel capacity: 35L | ||||||
| Max payload for the dump: 300Kgs | ||||||||
| Climbing Angle: 36 | Towing Capacity: 800KGS(1102LBS) | |||||||
