Specifications
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Color: |
Red Blue Black |
Wattage: |
200-250W |
Battery Voltage: |
24V |
Battery Type: |
Storage Battery |
Wheel Size: |
4 Inch |
Motor: |
Brush |
Frame Material: |
Steel |
Folded: |
Unfolded |
Max Speed: |
20-40km/h |
Range Per Power: |
10-30km |
Certification: |
EN15194, CE |
Product Description
Motor type:Brushed DC,250w/24v
Motor max loaded Amps:17.8A
Torque:1.21 (N.M)
Max Rpm:2700+-7.5% (rpm)
Controller type:air cooled,Non water-proof,brake shutoff,charger port
Battery:Lead-acid battery,12V/7AH X 2PCS
Charging time:6-8 hours
Battery charger:Input-100-240VAC,50/60HZ,1.8A Max,output-DC 24V,1.5A
Special features:dismountable handle bar/off road use wheel available
Turning angle:32 degree
Turning radius:no more than 1400mm
Transmission ratio:92/11
Seat height 440mm
wheel base distance 635mm
Front and rear Tire and rim:110/50-6.5
Maximum carrying capacity 45KGS
Mini ground clearance 90mm
Maximum speed:Low speed:11KM/H,high speed:21km/h
Maximum distance range:13km
Control system:handlebar control
Throttle type:turning control
Brake system:rear mechanical disc,left handle control
Drive system:chain drive
Brake disctance:no more than 2m(11km/h),no more than 4m(21km/h)
Packing size:950X285X520MM
Produce size:920X400X720MM
N.W/G.W:23/26KGS
Container quantity:200PCS/20FT ,500PCS/40HQ
