Specifications
Prod Model: |
FHSY-Snow Wolf |
Markets: |
North America,South America,Southeast Asia,Africa,Mid East,Eastern Asia |
Colour: |
Any |
Wheel Hub: |
Alloy Hubs |
Voltage Of Battery: |
48V |
Folded: |
Unfolded |
Motor: |
Brushless |
Battery Type: |
Lead-acid Battery |
Frame Material: |
Steel |
Maximum Loading Capacity: |
<75kg |
Running Distance: |
>60KM |
Charging Time: |
8-10h |
Wheel Size: |
14" |
Power: |
500W |
Max Speed: |
41km/H |
Brake: |
Front Disc Brake/Rear Drum Brake |
Product Description
Size: 1850 X 665 X 1090 mm
Wheelbase: 1310mm
Tire: 14´ X 3.2
Battery: 48V/60V, 20AH, 27.6KG/34.5KG
Weight: 56.2KG(without Battery and controller)
Controller: 12 tubes /120°
Footrest: Without
Color: Any color
OEM: OK
Model: |
FHSY-Snow Wolf |
|
|
Size(mm): |
1850 x 665 x 1090 |
Wheelbase(mm): |
1310 |
Max speed: |
41km/h |
Running distance: |
≥60km |
Motor: |
efficient\500W\metric\left outlet\120° |
Tire size: |
14'' x 3.2 |
Weight: |
56.2kg (without battery and controller) |
Battery: |
Lead-acid\48V/60V\20AH\27.6kg/34.5kg |
Charger: |
48V/60V\2.5A-3.0A |
Controller: |
12 tubes\120° |
Brake: |
Front disc brake/Rear drum brake |
Footrest: |
Without |
Charging hole requirements: |
Three vertical\N"+"\L"-" |
