Home Shenzhen Xinli Escooter Technology Co., Ltd. Self Balance E-Bike, Electric Scooter
Self Balance E-Bike, Electric Scooter
| Price: | US $ 880-1580/Piece |
|---|---|
| Trade Terms: | FOB,CIF,EXW |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,Western Union,Money Gram |
Specifications
| Prod Model: | ESOII |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: | Tour, Patrol Advertise, Lease, Transport Tool |
| Max.Speed: | 20km/H, Three Speed Modes |
| Package: | Wooden Case or Double Carton Box |
| Gross Weight: | 68kg |
| Max.Load: | 150kg |
| Name: | off Road Electric Skateboard |
| Type: | 2 Wheels |
| Board Material: | Aluminium Alloy |
| Wheel Kind: | Sliding |
| Customized: | Customized |
| Condition: | New |
| Age: | All Age |
| Kind: | Electric Scooter |
| Deck Material: | Aluminium Alloy |
| Usage: | Entertainment |
| Color: | 7 Colors Available. |
Product Description
self balance e-bike, electric scooter
Working principle of off road electric skateboard
Based on the basic principle of "motion stability", that is to say, vehicle's automatic balance ability, ESOI can judge the position, status of vehicle by its built-in precise solid-state gyroscope and then drive its motors to balance the vehicle after receiving the commands from high-speed CPU inside.
Driving ability of off road electric skateboard
With 2 strong motors, 800W per motor (2 motors can be 1600W), FreeGo 2 wheel scooter can move at the speed up to 18 km/h. Through a smart transmission, the ESOI drives 2 PCS of 16-inch high strength vacuum tires which makes it moves stable and comfortable no matter it is indoor or outdoor
The source of power
The power source of ESOI comes from the 2 rechargeable powerful batteries (12V@14AH) which can work for 2.5 hours and moves 30--35 km for one time fully charge.
Feature of off road electric skateboard:
1. New steering mechanism, more stable and comfortable, faster response
2. Updated process motherboard, more safe and easy to be controlled
3. Waterproof
4. Advanced design for steer and handle, beauty and fashion
5. More exquisite and light steering mechanism, more flexible turning
6. New model pedal with 4 detecting switch. Driver will not fall down in driving.
7. Adjusting big power importing motor. Max power of single wheel can achieve 800W, easy to climb continuously 30 degree slope.
8. Siren alarm, reminding the statue of scooter
9. GPS tracking is optional
10. High quality wheel with smooth racing tire.
Performance Parameter of off road electric skateboard
Max speed: 11.5 mph / 18 km/h
Dimension: 43*43*68 cm
Max load: 240 lbs / 110 kg
Battery: Two power lead acid
Motor: Two import DC Motor, DC servo drives
Wheel: 12 in / 26 cm Black Aluminum Rim
Tire: 17 in / 43 cm vacuum smooth
Height of footplate: 10in/26cm
Net Weight: 43 kg
Max distance: 30 km depends on terrain and driving skill
Packing list (Standard kits/parts)
Handle: 1 PC
Key: 2 PCS
User manual: 1 PC
Driving handle: 1 PC
Extra fuse: 4 PCS
Pedal mat: 2 PCS
Fender: 2 PCS
Tire: 2 PCS
Battery charger: 1 PC
Packing of off road electric skateboard
Inner: Carton, Outer: Plywood box
Gross weight: 58kg/carton
CTN demission: 47*47*74cm
Volume: 0.18cbm
135PCS/1container (20#)
| Net Weight | 56kg |
| Dimension | 91*54*72 cm |
| Max. cruise speed | 20km/h |
| Max. load | 150kg |
| Max. mileage | 30-35km |
| Max. climb capability | 30 degree |
| Min. turning radius | 0 degree |
| Charging time | 6-8h |
| Battery | PB, 36V, 48Ah |
| Voltage | 100v-240v |
| Max. power | 2000w (2*1000w/pc) |
| Life of battery | 1-3 years |
| Tire | 19inches vacuum,anti pucture |
| Wheel | Superior integrated aluminum magnesium alloy |
| Height of handle | 800-1100 mm adjustable |
| Height of footplate | 10inches |
| Specifications of footplate | 11.5*25 in |
| Max. height above ground | 120mm |
| Standard pressure | 250kpa |
| Colors | 7 colors available |
| Certifications | CE, FCC, ROHS |
