Specifications
Prod Model: |
NV5 |
Certification: |
ISO |
Product Description
The tire size: | 6.5inch solid tire |
max Speed | 12KM\H |
maximum loading | ≤120kg |
max Climbing degree | ≤20° |
max Range per charge | 20-30KM |
warning speed | 10KM/H |
Motor power | 350W*2 |
battery type | 20pcs 18650 power lithium battery,4.4AH |
wolt | input wolt:42V; out put wolt:36V |
current | input 2A; output:10A |
charging request | AC90-265V 47-63Hz |
Charging time | 2H |
Optimum discharge temperature | 20~30 ºC |
Pedal height | 110 mm |
The chassis height from the ground | 30 mm |
Waterproof and dustproof levels | IP54 |
Color | Black, White,Red, Gold, Blue, Green |
size&weigt for scooter | 584*186*178mm,10.5KG |
packing | Packaging:670*260*260mm,1PCS/CTN, G.W:13KG |
6.5inch tire,same as U010, just different outlook |
|
|
|
bluetooth is optional
Product warranty:
1.The scooter is 1 year warranty except for battery and material.
2.Battery is half one year warranty
3.Wheel is one month warranty, belongs to consumer goods.
4.Artificial damange is not in warranty.
Shipping charge statements(normal used damage)
1.Factory and buyer undertake half each within 30days;
2.Buyer undertakes the shipping charge out of 30days but in warranty
3.Factory won't undertake shipping charge and repair charge for artificial damage.
