Newest Outdoor Electric Motor Scooter

Specifications

Prod Model:	A1-8
Markets:	North America,South America,Eastern Europe,Southeast Asia,Oceania,Eastern Asia,Western Europe
Pas:	1:1 Intelligent Pedal Assistant System/Only Pedal
Battery:	36V8ah or 36V11ah Lithium Battery
Range:	1:1 Pas Mode 40-60km
Controller:	Intelligent Brushless 36V250W
Loading:	120kg
Tyre:	8"
Front Fork:	Steel
Derailleur:	Single Speed
Chain:	Aluminum,Cut-off When Braking Rust Resistant Chain
Package Size:	71*34*53cm
Motor:	Brushless
Wheel Hub:	Alloy Hubs
Certification:	En15194
Power:	200-250W
Voltage Of Battery:	36V
Frame Material:	Aluminum/Alloy
Battery Type:	Lithium Battery
Maximum Loading Capacity:	75-120kg
Running Distance:	45-60KM
Charging Time:	6-8h
Part:	Motor
Max Speed:	20-40km/h
Folded:	Folded
Brake:	Front V-brake / Rear Drum Brake
Wheel Size:	8"

Product Description

Newest Outdoor Electric Motor Scooter

electric scooter specification

Model	Shuangye A1-8H electric scooter
Motor	mini high speed brushless
	36V250W  25KM/H-30KM/H
	strong torque motor with ability of wonderful climbing and  splash proof,can riding within 5cm depth water
PAS	1:1 intelligent pedal assistant system/only pedal assistant
	1:1 intelligent pedal assistant and throttle
Battery	36V8Ah/36V 11AH Lithium battery
Range	1:1 PAS mode, 30-40KM
Controller	Intelligent brushless 36V250W
Charger	AC100V-240V,42V2A
Charging time	5-6 hours
Max speed	25km/h or 30km/h
Loading	120KG
Frame	Aluminum frame
Tyre	honeycomb hole non-inflatable wheel,without inner tire,anti  puncturing,durability more than 3 years.
Hub	Aluminum ally solid hub,1.5cm thick and not easy to deformation,durability more 3 years.
Damping system	front wheel with spring damping system.
Electron throttle	LED throttle with battery indicator
Certification	CE EN15194
Weight	N.W:14.5KGS
20'GP container	250 PCS(5.69*2.13*2.18)



Detailed Images

Standard configuration---single speeds.
                                              color yellow.(black/purple/Tyrant gold you can custom)
                                              8 inch mini tyre
                                              different Capacity you can choose

FAQ
1. What's the minimum ebike order MOQ?
    ebike A1 MOQ 10pc
2. How long is delivery time?
    2 days to 30 days, depend on model and quantity
3. Can I order spare parts?
   Yes, we have all parts list available for our models
4. How about warranty ?
    alloy frame 36 months, motor 24 months, lithium battery 15 months, controller 15 months.
5. Is sample available?
    Yes, sample order is acceptable, but there will be extra cost.
6. Can i choose the colors ?
    Yes, there would be extra cost.
7. What certificate do you have for electric bicycle?
    Every electric bicycle has CE/EN15194 certificate for EU
8. Could I use my own LOGO or design on goods?
    Yes. When order quantity is big, you can use your own LOGO or your language manual etc.
