Specifications
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Fuel Tank Capacity: |
5-8L |
Maximum Loading Capacity: |
75-120kg |
Engine: |
4 Stroke |
Displacement: |
51-125CC |
Certification: |
EEC |
Max Speed: |
>50km/h |
Product Description
Specification
Dimension(L*W*H) 1950*750*t1110mm
Carton Size(L*W*; H) 1860*785*1110mm
Wheelbase 1: 320mm
Min ground Clearance: 100mm
Net weight: 95kg
Max Load: 150kg
Wheel(front&rear): alloy wheel 2.15*10/2.15*10
Tire(front&rear: 3.50-10 4PR/3.50-10 4PR
Brake operation(front&rear) hand brake
Brake mode(front&rear) disk brake
Stop distance ≥ 7m(30km/h)
Engine forced: Air-cooling, single cylinder, 4 stroke
Rate power ≥ 5.3kw/7000rpm
Max Torque 7.3N. M/4000rpm
Max speed ≥ 80km/h
Start mode electric/foot
Transmission belt
Ignition mode EST
ECU type NC21
ECU mode 16bit
Battery YTX7L-BS/12V@6Ah
Fuel tank 5.8L
Replacement standard Euro III
Container Loading 40ft 38PCS
