Price: | US $ 605/Piece |
---|---|
Trade Terms: | FOB,CIF,others |
Min Order: | 10/Piece |
Pay Type: | L/C,T/T |
Specifications
Prod Model: | D409B |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Oceania,Mid East,Eastern Asia,Western Europe |
Seat: | One |
Max Load: | 110kg |
Running Distance: | 45-60KM |
Motor: | Brushless |
Battery Type: | Lithium Battery |
Frame Material: | Steel |
Voltage Of Battery: | 24V |
Power: | 251-350W |
Certification: | COC |
Wheel Hub: | Alloy Hubs |
Folded: | Folded |
Charging Time: | >10h |
Part: | Motor |
Brake: | Drum |
Max Speed: | 6.4km/H |
Maximum Loading Capacity: | 110kg |
Wheel Size: | 9" |
Product Description
Overall Dimentions (LXWXH) | 1135X555X940mm |
Max Forward Speed | 8km/h |
Max Backward Speed | 4km/h |
Braking Distance(≤) | 1.6m |
Max Climbing slope | 12degrees |
Ground Clearance | 50mm |
Loading Capacity | 110kg |
Turning radius | 1.45m |
Range per Change | 50km |
Front Tire | 9" |
Rear Tire | 9" |
Motor Rated Power | 250w |
Controller | PG S-Drive 45A |
Charger | 24V 2A |
Batteries(lead acid) | Lithium , 28V,20AHX2 |
Braking System | Electric Regenerative Braking |
N.W. | 55.6kg |
G.W. | 57.6kg |
Battery Weight(2pcs) | 5.6kg |
Packing Size: | |
Container packing | 20GP : 80 pcs 40GP : 168 pcs 40HQ : 168cps |
