Specifications
Prod Model: |
M01 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Color: |
Red, Green, Blue, Silver and So on . |
Material: |
ABS+UV |
Max Load(Kg): |
120 |
Battery: |
36V,4400mAh (Domestic, LG or Sumsang) |
Charging Voltage: |
AC 110-240V /50-60Hz |
Packaging Size(mm): |
650*260*260 |
Water And Dust Proof: |
IP54 |
20gp: |
650PCS |
40hq: |
1500PCS |
Product Description
SPECIFICATION
M01
Model No.:M01
Unit size (mm):584*168*178
Material :ABS+UV
Max Load(kg) :120
Max Speed(km/h):15-20
Max Mileage(km):20
Battery:36V,4400MAH (Samsung)
Motor Power(w):350*2
Max Tilt angle:≤ 30°
Net Weight(kg):12
The Charging Time(hr):2
Pedal Distance From Ground(mm):112
Tire size:6.5inch(171mm)
Charging Voltage:AC 110-240V /50-60Hz
Color:Red ,green, blue,silver and so on .
LED keeps twinkling under protection circumstances
Voice Alert Beeps:Turneon and has a low battery capacity
INTRODUCE
Safety Measures
1 Titlting Protection: 45° Side-to-side on average (Electric Scooter motor stalls when tilting over 45° )
2 Speed limit protection: Activated at 12Km/h (Electric Scooter front part of pedal will rise to prevent further acceleration)
3 Low Battery Protection: Activated on 15% power battery (Electric Scooterfront part of paddle will rise to decelerate will rise to decelerate till fully stop)
Alert
1 Power and Error Indication: LED Power Indicators (Red when turned on, blinks when protection activated. )
2 Battery Power: LED Power Level Indicators (Four bars on when over 85%; Off one by one as power level drops. )
3 Alert Sound: Beep (Beep when powered on; Continual beep when power level is dangerously low. )
4 Alert Sound: Long buzz (Long buzz when tilting sideways. )
Chinese Scooter
Attachments:
A. Manual
B. Charger(100-240V)
