Specifications
Prod Model: |
ZCN004 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Wheels: |
2 |
Age: |
Adult |
Body Material: |
Aluminum Alloy |
Wheel Material: |
PU |
Product Description
Basic infomation: Model ZCN004; Size 680*500*825mm; Gross weitht 5.41kg Net weight 4.04kg.
Scooter assembly by hand grips, bar, clamp, headset, fork, deck, wheel, brake, grip tape, compression.
Hand Grip: Model BT001; Material plastic; Length 130mm; Diameter 30mm; Aperture 22mm; Weight 0.1kg.
Bar: Model HB008; Material Iron4130; Width 500mm; Height 500mm; Diameter 31.8mm; Aperture 28.6mm; Weight 1.12kg.
Clamp: Model SZ001; Material Aluminum6061; Height 70mm; Diameter 49mm; Aperture 35mm; Weight 0.14kg.
Headset: Model WZ004; Material Ball-Bearing Steel; Height 6.5mm; Diameter 41.8mm; Aperture30mm; Weight 0.02kg.
Fork: Model QC003; Material Aluminum6061; Height 280mm; Diameter 57mm; Aperture 30mm; Weight 0.47kg.
Deck: Model DN001; Material Aluminum6061; Length 610mm; Width 125mm; Height 205mm; Weight 1.34kg.
Wheel: Model LZ003; Material Aluminum6061+PU; Width 24mm; Diameter 110mm; Aperture 22mm; Weight 0.23*2kg.
Brake: Model SC001; Material Spring 65M Steel; Length 100mm; Width 43mm; Height 70mm; Weight 0.19kg.
