HONDA CRF 150CC / 200CC Dirt Bike (HN-DB001)

Specifications

Prod Model:	HN-DB001

Product Description

ENGINE
Displacement - 149cc
Type - 4 Stroke Single Cylinder
Cooling - Air-Cooled
Transmission - Manual 4 Speed w/ Clutch
Shifter - Long / Folding
Drive Train - Chain
Ignition - Kick Start/CDI
Compression Ratio - 10: 1
Bore & Stroke - 61MM x 49.5MM
Valve Train - SOHC: Two Valve
Final Drive - #428 14T Front / 43 T
Maximum Speed - ≥90 KM/H (56 MPH)
Maximum Power: 8.8 HP @ 8500 RPM
Fuel: Unleaded
Fuel Capacity: 3L (0.8 Gallons)
Oil Tank Capacity: 0.25 Gallons (0.95L)

SUSPENSION
Front Suspension: Alloy upside down rebound dampening with reservoir
Rear Suspension: Adjustable preload and rebound dampening with reservoir
Front Fork Travel: 5 inches
Rear Fork Travel: 7 inches

BRAKES
Front Brake: Hydraulic disk 240MM
Rear Brake: Hydraulic disk 190MM

TIRES & RIMS
Front Tire: 2.50 x 19 Tire
Rear Tire: 2.75 x 16 Tire
Front Rim: Anodized Aluminum 19"
Rear Rim: Anodized Aluminum 16"

DIMENSIONS
Wheelbase: 1260MM(49.61 Inches)
Seat Height: 780MM(30.71 Inches)
Bar Height: 1070MM(42.13 Inches)
Dry Weight: 73KG (160 LBS)
Spark Plug: C7HSA
Crate Dimensions: 1590 x 435 x 840MM (63 x 18 x 34 Inches)
Frame: Chromo
Seat: 40mm Tall Gripper
Seat Color: Optional
Grips: 2 Stage Compound
Silencer: Steel Performance Head Pipe & Muffler
Pegs: Oversized Steel
