Specifications
| Prod Model: | S-G500L-01 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certificate: | CE EPA Go Kart |
| Start-up: | Electric |
| Transmission: | Automatic |
| Displacement: | >400CC |
| Certification: | EPA |
Product Description
EngineType: 500CC single-cylinder, 4-stroke, liquid cooling
Bore x Stroke: 87.5mm x 82.0mm
Max power: 32HP
Starting system: E-start
Max speed: 90km/h
Compression ratio: 10.2: 1
Ignition: CDI
Suspension/Brake/Wheels
Suspension: 4-wheel independent suspension
Brake/front: Hydraulic disc
Brake/rear: Hydraulic disc
Wheels/front: 25 x 8-12
Wheels/rear: 25 x 10-12
Dimensions/Packing
LxWxH: 2850 x 1600 x 1500mm
Wheelbase: 2190mm
Ground clearance: 350mm
Tank capability: 32L
Qty/20 FCL: 4PCS
Qty/40 HQ: 12PCS
Others
Transmission: C. V. T Automatic clutch (R/N/L/H)
Drive: Shaft drive, 2x4 & 4x4 swithable, front-differential
Dry weight: 520kg
