Specifications
| Prod Model: | 650cc |
|---|
Product Description
Product Name: Go KartModel Number: 650cc
Place of Origin: China
Features:
1) Engine: LJ276M
2) Type: 2 cylinders, 4 strokes, water-cooled, in-line and steep style, half-ball
fire box
3) Start method: electromagnetism operation, compulsory engage
4) Cylinder x course: 76 x 71mm
5) Displacement: 644ml
6) Pressure: 8.4:1
7) Ignition: battery
8) Lubrication: pressure, splash
9) Max. power: 20.6/4500kW(r/min)
10) Standard power: 44/2700 - 330N.m(r/min)
11) Lowest oil wear when max. power >329g/kwh
12) Loading: 900+/-50r/min
13) Clutch: single disc, diaphragm spring, dry
14) Clutch operation: compulsory
15) Engine net weight: 86kg
16) Complete go-car weight: 370kg
17) Engine dimensions (length x with x height): 830 x 530 x 435mm
18) Go-cart dimensions (length x with x height): 2,450 x 1,650 x 1,530mm
19) Wheel base: 1,770mm
